PG Plus 500 FID Tower Hydrogen + Zero Air Generator

PG Plus 500 FID Tower Hydrogen + Zero Air Generator


Price: Quote Only

+

Overview

The space-saving PG Plus 500 FID Tower Hydrogen + Zero Air Generator uses the latest proton exchange membrane (PEM) technology to produce pure hydrogen.


De-ionized water is automatically loaded from smart internal system tanks with a 3 liter capacity, providing up to 3000 liters of H2 before a refill is required. The only recommended maintenance is replacement of the internal deionizing cartridge, which has been greatly simplified.


PG PLUS 500 FID TOWER FEATURES:
▪︎ Flow rate 500 mL/min
▪︎ Zero Air flow rates 1.8 L/min or 5 L/min
▪︎ Purity >99.9996%
▪︎ Pressure up to 11 barg (160 psig)
▪︎ Unique patented membrane drying system
▪︎ Proprietary 100% titanium cell technology
▪︎ USB connectivity
▪︎ 2 year standard warranty


Part# DB-FTHG500-EU (230-240V/50-60Hz)
Part# DB-FTHG500-US (115V/60Hz)
Part# DB-FTHG500-JP (100V/60Hz)


GC APPLICATIONS
▪︎ GC-FID FUEL GAS
▪︎ GC-FPD FUEL GAS
▪︎ GC-NPD PLASMA GAS


ANALYZER APPLICATIONS
▪︎ TOTAL HYDOCARBON ANALYZER (THA) FUEL GAS


Other Lab Application

▪︎ HYDROGEN REACTORS
▪︎ HYDROGEN FUEL CELLS

The following options are available:
▪︎ I/O board
▪︎ Remote control software (RS232 or USB)
▪︎ Cascading hardware (standard or high purity)
▪︎ H2 Sensor

Flow mL/min500
Purity>99.9996%
Dew point at 7 barg (100 psig)-25 ºC (-77 ºF)
Outlet pressure barg (psig)0.5 to 11 (7 to 160)
TechnologyPEM (Proton Exchange Membrane) - 100% Titanium cell
Drying systemRegenerative Permeation Membrane
Deionized water qualityminimum <1 μS/cm @25 ºC - 1 MΩ-cm@25 ºC - ASTM II
recommended <0.2 μS/cm @25 ºC - 5 MΩ-cm @25 ºC - ASTM II
Internal water tank liters5
SafetyAutomatic shut down - internal/external hydrogen leak, overpressure and low water
DisplayTouch screen with operating parameters, system status and safety alarms
LED indicatorsPower on/off, system ready, errors
InterfaceUSB mod A
Electrical supply110-120V 60Hz / 220-240V 50Hz
Power consumption watts180
Product Dimensions mm (in)140W x 490H x 580D (5.5W x 19H x 22.8D)
Product Weight kg (lb)24 (53)
Shipping Dimensions mm (in)770W x 590H x 410D (30.3W x 23.2H x 16.1D)
Shipping weight kg (lb)28 (62)
Operating temperature ºC ( ºF)15 to 35 (59 to 95)
Outlet connection1/8" compression
CertificationCE, FCC, MET (UL and CSA compliant)



+ Zero Air Generator Module Specs


Flow mL/min

18005000
Purity - hydrocarbons + CO<0.1 ppm<0.1 ppm
Inlet pressure barg (psig)4.5 to 10 (65 to 145)
Inlet air qualityClean dry compressed air ISO8573-1:2010 Class 1.2.1
Max outlet pressure barg (psig)5 (73)
Max HC in100 ppm
Max CO in50 ppm
